Inovance IS300T080-C User Manual

- 31 -
The Servo pump work process would lead to vacuum state,in order to prevent
air entering the pressure sensor intra-cavity that cause the pressure sensor
damaged,please ensure the pressure sensor cavity always retain hydraulic oil,
Please follow the oil pressure sensor installed vertically upward, as shown at
the fllowing.
Fig.3-5Pressure Sensor Installtion Mode
3.2 Electrical Installation
3.2.1 Guide to the external electrical parts:
Table 3-1 Guide to Prototyping of External Electrical Parts of IS300 servo
driver
Servo
Driver
Modle
Circui
t
break
er(MC
CB)
(A)
Reco
mme
nded
Cont
actor
(A)
Recomm
end-ed
Input
filterA
Recomm
end-ed
Conduct
ing Wire
of Main
Circuit
at the
Input
Side
mm
2
Recomm
ended
Conducti
ng Wire
of Main
Circuit at
the
Output
Side
mm
2
Recomm
e-nded
Conduct
ing Wire
of
Control
Circuit
mm
2
IS300T005 25 16 25 4 4 1.5
IS300T010 32 25 35 4 4 1.5
