161
Specifications
Amplifier Section
Video Section
Tuner Section
General
Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
■ Control Terminal
Specifications and features are subject to change without
notice.
Input Sensitivity and Impedance
200 mV/47 kΩ (LINE)
2.5 mV/47 kΩ, (PHONO MM)
Output Level and Impedance
200 mV/470 Ω (REC OUT)
Phono Overload 70 mV (MM 1 kHz 0.5 %)
Frequency Response 5 Hz - 100 kHz/+1 dB - 3 dB
(Direct mode)
Tone Control ±10 dB, 50 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 110 dB (LINE, IHF-A)
80 dB (PHONO, IHF-A)
Input Sensitivity/Output Level and Impedance
1 Vp-p/75
Ω
(Component and S-Video Y)
0.7 Vp-p/75
Ω
(Component P
B
/C
B
, P
R
/C
R
)
0.28 Vp-p/75 Ω (S-Video C)
1 Vp-p/75 Ω (Composite)
Component Video Frequency Response
5 Hz - 100 MHz - 3 dB
FM Tuning Frequency Range
North American:
87.5 MHz - 107.9 MHz
Australian:
87.5 MHz - 108.0 MHz, RDS
AM Tuning Frequency Range
North American:
530 kHz - 1710 kHz
Australian:
522 kHz - 1611 kHz
Preset Channel 40
Digital Tuner (North American models only):
SIRIUS
Power Supply North American:
AC 120 V, 60 Hz
Australian:
AC 220 - 240 V, 50/60 Hz
Power Consumption North American: 1.2 A
Australian: 110 W
Dimensions (W × H × D)
435 × 198.5 × 445 mm
17-1/8" × 7-13/16" × 17-1/2"
Weight 13.5 kg (29.8 lbs.)
HDMI IN1 (DVD/BD), IN2 (VCR/DVR),
IN3 (CBL/SAT), IN4 (GAME),
IN5 (AUX2), IN6, IN7, AUX1 (Front)
Component IN1 (DVD/BD), IN2 (CBL/SAT),
IN3 (GAME)
S-Video DVD/BD, VCR/DVR, CBL/SAT,
GAME
Composite DVD/BD, VCR/DVR, CBL/SAT,
GAME, AUX1 (Front)
PC INPUT Analog RGB
1
HDMI OUT MAIN, OUT SUB
Component MONITOR OUT, ZONE 2 OUT
S-Video MONITOR OUT,
VCR/DVR (REC OUT)
Composite MONITOR OUT,
VCR/DVR (REC OUT), ZONE 2 OUT
Digital Inputs Optical: 3 (Rear), 1 (Front)
Coaxial: 3 (Rear)
Analog Inputs MULTI CH, DVD/BD, VCR/DVR,
CBL/SAT, GAME, AUX2, TV/TAPE,
CD, PHONO, AUX1 (Front)
Balance Inputs 2
Multichannel Inputs 7.1
Analog Outputs TV/TAPE, VCR/DVR,
ZONE 2 PRE OUT, ZONE 3 PRE OUT
Balance Pre Outputs FL, FR, C, SL, SR, SBL, SBR,
LH/LW, RH/RW, SW1, SW2
Multichannel Pre Outputs
9
Subwoofer Pre Outputs
2
Phones 1
MIC Yes
RS232 1
Ethernet 1
IR Input 2
IR Output 1
12 V Trigger Out 3
USB 2 (Front and Rear)
