Connecting the AV controller—Continued
Connecting a Camcorder or Other Device
Connection AV controller Signal flow Camcorder etc.
AUX1 Input Video ⇐ Composite video output
AUX1 Input L-Audio-R ⇐ Analog audio L/R output
AUX1 Input Digital ⇐ Digital optical output
Step 1: Video Connection
Make the connection .
A
Step 2: Audio Connection
Choose an audio connection that matches your camcorder ( or ), and then make the connection.
a b
A
a
b
AUDIO
OUT
VIDEO
OUT
LR
Video
Audio
LR
AUX1 InputAUX1 Input
OPTICAL
OUT
Digital
AUX1 Input
A b
a
Camcorder etc.
