Case Temperature Reference Metrology
R
76 Thermal/Mechanical Design Guide
D.3 Supporting Test Equipment
To apply the reference thermocouple attach procedure, it is recommended to use the equipment
(or equivalent) provided in the following table.
Item Description Part Number
Measurement and Output
Microscope Olympus Light microscope or equivalent SZ-40
DMM Digital Multi Meter for resistance measurement Not Available
Test Fixture(s)
Micromanipulator
(See Note below)
Micromanipulator set from YOU, Ltd. or equivalent.
Mechanical 3D arm with needle (not included) to maintain
TC bead location during the attach process.
YOU-3
Miscellaneous Hardware
Loctite 498
Adhesive
Super glue w/thermal characteristics 49850
Adhesive
Accelerator
Loctite 7452 for fast glue curing 18490
Kapton Tape For holding thermocouple in place Not Available
Thermocouple Omega,40 gauge, “T” Type 5SRTC-TT-T-40-72
Calibration and Control
Ice Point Cell Omega, stable 0 ºC temperature source for calibration and
offset
TRCIII
Hot Point Cell Omega , temperature source to control and understand
meter slope gain
CL950-A-110
Note: Three axes set consists of (1ea. U-31CF), (1ea. UX-6-6), (1ea. USM6), and (1ea. UPN-1). More
information available at: http://www.narishige.co.jp/you_ltd/english/products/set/you-set.htm#3
