Intel® Server Board S5500WB TPS Appendix B: Video POST Code Errors
Revision 1.3
Intel order number E53971-004
95
Appendix B: Video POST Code Errors
Whenever possible, the BIOS outputs the current boot progress codes on the video screen.
Progress codes are 32-bit quantities plus optional data. The 32-bit numbers include class,
subclass, and operation information. The class and subclass fields point to the type of hardware
being initialized. The operation field represents the specific initialization activity. Based on the
data bit availability to display progress codes, a progress code can be customized to fit the data
width. The higher the data bit, the higher the granularity of information that can be sent on the
progress port. The progress codes may be reported by the system BIOS or option ROMs.
The Response section in the following table is divided into three types:
No Pause: The message is displayed on the local Vidoe screen during POSTor in the
Error Manager. The system continues booting with a degraded state. The user may want
to replace the erroneous unit. The setup POST error Pause setting does not have any
effect with this error.
Pause: The message is displayed on the Error Manager screen, and an error is logged
to the SEL. The setup POST error Pause setting determines whether the system pauses
to the Error Manager for this type of error, where the user can take immediate corrective
action or choose to continue booting.
Halt: The message is displayed on the Error Manager screen, an error is logged to the
SEL, and the system cannot boot unless the error is resolved. The user needs to replace
the faulty part and restart the system. The setup POST error Pause setting does not
have any effect with this error.
Table 57. POST Error Messages and Handling
Error Code Error Message Response
0012 CMOS date / time not set Major
0048 Password check failed Major
0108 Keyboard component encountered a locked error. Minor
0109 Keyboard component encountered a stuck key error. Minor
0113
Fixed Media The SAS RAID firmware can not run properly. The user should
attempt to reflash the firmware.
Major
0140 PCI component encountered a PERR error. Major
0141 PCI resource conflict Major
0146 PCI out of resources error Major
0192 Processor 0x cache size mismatch detected. Fatal
0193 Processor 0x stepping mismatch. Minor
0194 Processor 0x family mismatch detected. Fatal
0195 Processor 0x Intel(R) QPI speed mismatch. Major
0196 Processor 0x model mismatch. Fatal
0197 Processor 0x speeds mismatched. Fatal
0198 Processor 0x family is not supported. Fatal
019F Processor and chipset stepping configuration is unsupported. Major
5220 CMOS/NVRAM Configuration Cleared Major
5221 Passwords cleared by jumper Major
