Intel® Server Board S5500WB TPS Server Board Overview
Revision 1.3
Intel order number E53971-004
7
Table 2. Intel
®
Server Board S5500WB System Interconnects
Description Description
A Dual Intel
®
I/O Expansion Module
Connectors
V Processor Socket 1
B PCI Express x16 Gen2 W 8 Pin CPU Connector
C Remote Management Module 3 X Processor Socket 2
D POST Code LEDs Y 4-pin Fan Connector (CPU2)
E External I/O Z 4-pin Fan Connector (CPU2A)
F USB Connector AA 4-pin Fan Connector (MEM2)
G Battery BB 8-pin Fan Connector (MEM2R)
H SATA Connectors CC DIMM Slot D2
I 24 Pin Connector (SSI only) DD DIMM Slot D1
J 8 Pin Connector (12V only) EE DIMM Slot E1
K Aux Power (5-pin or 7-pin) FF DIMM Slot F1
L RAID Key GG Front Panel Connector
M DIMM Slot C1 HH HDD LED Header
N DIMM Slot B1 II Low-Profile USB Connector
O DIMM Slot A1 JJ Internal VGA Connector
P DIMM Slot A2 KK BMC Power Cycle Header (12V Only)
Q 8-pin Fan Connector (MEM1R) LL USB Connector
R 4-pin Fan Connector (MEM1) MM Slot 1 PCI Express x8 Gen2
S 4-pin Fan Connector (CPU1A) NN SGPIO Connector
T 4-pin Fan Connector (CPU1) OO IMPB Connector
U HDD Power Connector (12V only) PP Serial Port B
