Intellian v240M User Manual

v240M – Marine Satellite Communication System
16
Installation Kit
ACU Box Components
Description Q'ty Size Remarks
ACU 1 43.1 x 38 x 4.4cm Antenna Control Unit
Wi-Fi Antenna 1
ACU Side Bracket (Rack) 2 ACU to 19inch Rack
ACU Side Bracket (Table) 2 ACU to Table
USB Cable (A-A) 1 1.8m ACU to PC
D-Sub 9 pin Male Connector 2 ACU
N to F Adaptor 1 N(Male) to F(Female) Adaptor
USB Flash Drive 1
User Manual 1
Self-Tapping Screw 5 M4 x 16L
Bolt Kit for ACU Rack
Mount Bracket
Sems Bolt 5 M3 x 12L
Flat Head Screw 10 M4 x 12L
Cable Kit Components
Description Q'ty Size Remarks
RG6 Cable 1 3m ACU to Modem
AC Power Cable (CEEE7/7) 1 1.5m ACU Power (220V)
AC Power Cable (USA) 1 1.8m ACU Power (110V)
PC Serial Cable 1 1.8m ACU to PC
iDirect Interface Cable 1 1.5m ACU to Modem
Comtech Interface Cable 1 1.5m ACU to Modem
iDirect Modem Cable Pin
Connection Manual
1
LAN Cable for Intellian M&C 1 1.8m
Rope Box Components
Description Q'ty Size Remarks
Fixed Rope 1 5m Fix to Antenna Assembly
EL Weight Plate Side R 2 Antenna Assembly
EL Weight Plate Side L 2 Antenna Assembly
C-Feeder Fixed Bar 1 Antenna Assembly
