Intellian v240M User Manual

175
TECHNINCAL SPECIFICATION
Technical Specication
Dimensions
Satellite Antenna Unit (with Base Frame) 390cm x 414cm (153.5" x 162.9")
Antenna Dish Diameter 240cm (94.5")
Antenna Control Unit 43.1cm x 38.1cm x 4.4cm (17" x 15" x 1.7")
Weight
Satellite Antenna Unit (with Radome) 880kg (1940 lbs)
Antenna Control Unit 3.5kg / 7.7lbs
Antenna System Performance (VM2-240-PXX)
Tx Frequency
5.85 GHz ~ 6.425 GHz C-Band
13.75 GHz ~ 14.5 GHz Ku-Band
Tx Gain
42.6 dBi @ 6.14 GHz C-Band
49.1 dBi @ 14.25 GHz Ku-Band
Rx Frequency
3.625 GHz ~ 4.2 GHz C-Band
10.7 GHz ~ 12.75 GHz Ku-Band
Rx Gain
39.0 dBi @ 3.91GHz C-Band
48.2 dBi @ 11.82 GHz Ku-Band
Polarized Feed
Ku-band: Linear (Cross-pol & Co-pol)
C-band: Linear & Circular
Cross-pol Isolation 30 dBc Typical
G/T
20.3 dB/K C-Band (Clear sky, 30
° elevation)
28.0 dB/K Ku-Band (Clear sky, 30° elevation)
Azimuth Range Unlimited with home sensor (no limit switch)
Elevation Range -15
° ~ +120°
Cross-level Range
±
30°
Stabilization Accuracy 0.2° peak mis-pointing @max. ship motion condition
Max Ship's Motion
±
25° roll,
±
15° pitch,
±
8° yaw @ 6 sec
Turning Rate Up to 10
°/ sec
2
BUC C-Band 40~200W, Ku-Band 8~40W
Power Consumption
100~240 V AC, 50~60 Hz, 1A
Antenna Control Unit (VP-T537)
Display 2 Line 40 Character Graphic VFD Module
PC Interface RS232C (57600 bps, 8, N, 1), USB
Modem Interface Ethernet port, RS232C, I/O ports
RF Interface Antenna Rx: N-type, Modem Rx: F-type
Gyrocompass Interface NMEA2000, NMEA0183
GPS Interface NMEA In, NMEA Out
Remote access RJ45, TCP/IP
Power consumption 100~240V AC, 50~60Hz, 1A
