Intellian v240M User Manual

69
OPERATION INSTRUCTION
INTELLIAN TECHNOLOGIES INC.
1. The data communication is being established between the antenna and the ACU.
INITIALIZE - ANTENNA INFO
INTELLIAN v240M
2. The ACU receives antenna information.
INITIALIZE - EL POSITION
INTELLIAN v240M
3. The elevation angle and cross level angle are initialized.
INITIALIZE - AZIMUTH POSITION
INTELLIAN v240M
4. The azimuth angle is initialized.
INITIALIZE - SAT POSITION
INTELLIAN v240M
5. The antenna returns to the target satellite position.
SEARCH1 125.0E ASIA6AH SIG:101 C
AZ:150.7( 150.7) EL: 45.3 SK: 02.0
6. The antenna is searching for the target satellite.
TRACKING 125.0E ASIA6H SIG:201 c
AZ:181.7( 181.7) EL: 47.3 SK: 02.0 Fn
7. The antenna has locked onto the satellite.
Startup
With the system is installed and power applied, the ACU screen will show the
following sequence.
Normal Mode
Start up
Initialize antenna info
Initialize elevation &
cross level angle
Initialize azimuth angle
Initialize target satellite
position
Search status
Tracking status
