Intellian v240M User Manual

v240M – Marine Satellite Communication System
82
Password
Antenna menu
Set parameters menu
Setup mode
Set detect & tracking DVB
Setting Search Parameters
SETUP MODE ?
4
YES NO
1. Press the LEFT arrow key to move the cursor to YES and press the OK key to enter SETUP
mode.
4
+ANTENNA +SATELLITE
+SYSTEM +INSTALLATION
2. Press the OK key to enter the ANTENNA menu.
+MANUAL SEARCH + SET POL ANGLE
+SEARCH PARAM
4
+SET PARAMETERS
3. Press the arrow keys to move the cursor to the SET PARAMETERS menu and press the OK
key to enter it.
ENTER PASSWORD
- - - -
4. Enter the 4 digit password to enter the SET PARAMETERS MODE (1590).
Setup parameters are only required after installation or repairs to your antenna system.
These parameters should only be changed by an authorized service technician.
Improper setting of these parameters will render your system inoperable.
5. Set DETECT DVB and TRACKING DVB when the DVB mode of TRACKING SIGNAL is
being used (Range : 1-200). DETECT DVB is to set the satellite signal detection level and
TRACKING DVB is to set the satellite signal tracking level.
Press the LEFT and RIGHT arrow keys until the desired character is underscored (selected).
Press the UP and DOWN arrow keys to increase and decrease the selected character.
Or press the NUMBER keys to set the desired value directly. Press the OK key to set the
parameter. Press the BACK key to select the parameter you wish to edit and press the BACK
key again to save or abort and return to the main display.
KU DETECT DVB KU TRACKING DVB
040 020
C DETECT DVB C TRACKING DVB
040 020
