Chapter 3: System functions
88 Advisor Advanced ATSx500A(-IP) Installation and Programming Manual
User programmable functions
You can program your own user functions that can later be activated
automatically or manually. For example, you can program a user function for
setting an area or switching on an output, and then define a schedule for it.
Programming menu
The function programming menu is accessible from various menus where user
programmable functions are used.
The list of allowed functions may vary for different menus.
To program a user function:
First, choose an appropriate function type.
Note: Depending on the user menu entry, you may need to select an object type
first, for example, Door or Area.
Next, configure function parameters.
Available parameters depend on the selected function type. For particular types
parameters are disabled.
Note: Particular functions require user code entering. To disable it, switch off the
“User Code Req” parameter, if allowed.
Depending on the activation method, the following function types and parameters
may be available.
Table 18: Available function types and parameters
1. Areas selection
2. Area groups selection
3. User code requirement
1. Areas selection
2. Area groups selection
1. Trigger name
2. State change: Clear, Set, or Toggle
Part set 1 for areas [1][2]
1. Areas selection
2. User code requirement
