Intermec PF8D User Manual

Appendix A — Printer Specifications
PF8d and PF8t Desktop Printer User’s Guide 69
Polyethylene Plastics
Polyethylene plastics are resistant to water and many common
chemicals, as well as tearing. Use this media with HP/TMX2200
ribbons for outdoor applications.
Polyesters
Polyesters are the media of choice in combination with
HR/TMX3201/TMX3202 ribbons. This media is highly resistant to
chemicals, heat, and mechanical abrasion.
Labels
Non-Continuous
Examples of Polyethylene Plastics
Europe North America
TTR Polyethylene Duratran II Kimdura
TTR Gloss Polyethylene Duratran II Synthetic Tag
Duratran II Syntran
Examples of Polyesters
Europe North America
TTR High Gloss Polyester Duratran II Gloss Polyester
Media Specifications
Measurement Value
Maximum media width, includes liner (a) 116.0 mm (4.57 in)
Minimum media width, includes liner (a) 25.0 mm (1.0 in)
Minimum label length (b) 12.0 mm (0.5 in)
Maximum label gap height (c) 10 mm (0.39 in)
Minimum label gap height (c) 3.0 mm (0.12 in)
Liner opacity 75%

Intermec PF8D Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
RS-232 ports	1
Standard interfaces	USB 2.0
Connectivity technology	Wired
Flash memory	4 MB
Certification	CE, FCC Class A, cULus, UL, GS, TUVGS, CCC, C-TICK, BSMI
Internal memory	8 MB
Built-in barcodes	MaxiCode, PDF417
Page description languages	EPL
Form factor	Desktop
Dimensions (WxDxH)	168 x 218 x 116 mm
Compatible operating systems	Windows 98/Me/2000/XP Pro/Server 2003/Vista
Core diameter	25.4 mm
Ribbon length	274.32 m
Maximum media length	1727 mm
Maximum roll diameter	127 mm
Supported paper width	104 mm
Maximum media length (imperial)	68 \
Supported paper width (imperial)	4.1 \
Power requirements	100–240 V AC/50–60 Hz, 1.9 A
AC adapter output current	3 A
AC adapter output voltage	24 V
Storage temperature (T-T)	40 - 104 °F
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	2000 g
