Appendix A — Printer Specifications
74 PF8d and PF8t Desktop Printer User’s Guide
Accessories for the Printer
These accessories for the PF8 printers are sold and ordered separately:
• Cutter Kit: The cutter is designed to cut continuous paper-based
stock or liner between labels.
• Self-Strip Module: The self-strip feature peels the label away from
the liner (backing paper) as it prints for faster on-demand labeling.
• CompactFlash Adapter (PF8t only): This adapter lets you install a
CompactFlash card in your PF8t printer to increase the memory
size.
You can also order serial and parallel cables, media, and transfer
ribbons. For help, contact your local Intermec sales representative.
The cutter kit and self-strip module must only be installed
by an authorized service technician. Intermec assumes no
responsibility for personal injury or damage if the installation
is performed by an unauthorized person.

Intermec PF8D Specifications

General

Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
RS-232 ports	1
Standard interfaces	USB 2.0
Connectivity technology	Wired
Flash memory	4 MB
Certification	CE, FCC Class A, cULus, UL, GS, TUVGS, CCC, C-TICK, BSMI
Internal memory	8 MB
Built-in barcodes	MaxiCode, PDF417
Page description languages	EPL
Form factor	Desktop
Dimensions (WxDxH)	168 x 218 x 116 mm
Compatible operating systems	Windows 98/Me/2000/XP Pro/Server 2003/Vista
Core diameter	25.4 mm
Ribbon length	274.32 m
Maximum media length	1727 mm
Maximum roll diameter	127 mm
Supported paper width	104 mm
Maximum media length (imperial)	68 \
Supported paper width (imperial)	4.1 \
Power requirements	100–240 V AC/50–60 Hz, 1.9 A
AC adapter output current	3 A
AC adapter output voltage	24 V
Storage temperature (T-T)	40 - 104 °F
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	2000 g
