Invacare Leo Operating Manual

40
7.4 Adjusting the seat height
The seat height can be adjusted to 43, 45, 47, or 49 cm.
CAUTION! Hazards due to unintentional disengaging of drive!
• Do not use the top drill hole! The seat is too low in this position and is not at a sufficient
distance from the enclosure or disconnection lever!
Requirements:
• 2x open-ended spanners 17 mm
• Remove the seat
• Remove the battery and motor compartment cover.
• Remove the seat pillar locking bolt using both open-
ended spanners.

Invacare Leo Specifications

General

Maximum Speed	8 km/h
Weight Capacity	136 kg
Ground Clearance	7 cm
Battery	2 x 12V
Seat Width	47 cm
Seat Depth	41 cm (16.1 inches)
Maximum Safe Slope	10 degrees
Turning Radius	43.3 inches (110 cm)
