Invacare Leo Operating Manual

58
11.2 Removing the battery and drive unit
• Once you have removed the seat, remove the battery and motor compartment cover panel.
The cover panel is secured using a velcro band, so you only need to pull it upwards to remove
it.
11.2.1 Removing the batteries
Please see chapter "Removing and fitting batteries" on page 47 for information on removing the
batteries.
11.2.2 Removing the drive unit
• Separate the main wiring harness connecting plug
(1).

Invacare Leo Specifications

General

Maximum Speed	8 km/h
Weight Capacity	136 kg
Ground Clearance	7 cm
Battery	2 x 12V
Seat Width	47 cm
Seat Depth	41 cm (16.1 inches)
Maximum Safe Slope	10 degrees
Turning Radius	43.3 inches (110 cm)
