Invacare Leo Operating Manual

61
13 Technical Specifications
Permissible Operating and
Storage Conditions
Temperature range for operation
according to ISO 7176-9:
• -25 … +50 °C
Temperature range for storage
according to ISO 7176-9:
• -40 … +65 °C
Electrical system
Motors
• 1 x 240 W
Batteries
• 2 x 12V / 36 Ah, leakproof/gel
Main fuse
• 70 A
Charging device
Output current
• 5A ±
Output voltage
• 24V nominal (12 cells)
Input voltage
• 200 – 250V nominal
Operating temperature
(surroundings)
• -25° ... +50°C
Storage temperature
• -40° ... +65°C
Tyres
Tyre type
• 3.00 - 4 pneumatic
Tyre pressure
• 2.8 bar
Driving characteristics
Speed
• 8 km/h

Invacare Leo Specifications

General

Maximum Speed	8 km/h
Weight Capacity	136 kg
Ground Clearance	7 cm
Battery	2 x 12V
Seat Width	47 cm
Seat Depth	41 cm (16.1 inches)
Maximum Safe Slope	10 degrees
Turning Radius	43.3 inches (110 cm)
