Maintenance
Fuel System
107 9831/7750-1 107
4. Drain the trapped water from the bowl.
5. Remove the bowl and electrical connection (if any).
6. Place a suitable container to catch any fuel. Remove the filter element. Refer to Figure 61.
7. Clean around the filter base seal area.
8. Apply a thin film of oil on the gasket surface of the new filter.
9. Fill the filter element with clean fuel before installing.
10. Install the filter element onto the filter head until the gasket contacts the head. Hand tighten the filter an
additional one half to three quarter of a turn.
11. Install the bowl.
12. Bleed the fuel system.
Refer to: Bleed (Page 103).
13. Run the engine and make sure there are no fuel leaks.
Figure 61.
A Filter element B Bowl
Water Separator
Clean
1. Make the machine safe.
Refer to: Maintenance Positions (Page 87).
2. Open the engine compartment cover to get access to the filter.
3. Examine the water separator bowl for sediment.
3.1. If there is water but no sediment, open the tap to drain the water.
3.2. If there is any sediment in the bowl, replace the fuel filter element.
