Operation
Transporting the Machine
62 9831/7750-1 62
Transporting the Machine
General
WARNING The safe transit of the load is the responsibility of the transport contractor and driver. Any
machine, attachments or parts that may move during transit must be adequately secured.
CAUTION Before moving the machine onto the trailer, make sure that the trailer and ramp are free from
oil, grease and ice. Remove oil, grease and ice from the machine tyres. Make sure the machine will not
foul on the ramp angle.
Check the condition of the transport vehicle before the machine is loaded on to its trailer.
Make sure that the transport trailer is suitable for the dimensions and weight of your machine. Refer to: Static
Dimensions (Page 129).
Before transporting the machine make sure you will be obeying the local rules and laws regarding machine
transportation of all the areas that the machine will be carried through.
Loading the Machine onto the Transporting Vehicle/Trailer
WARNING The safe transit of the load is the responsibility of the transport contractor and driver. Any
machine, attachments or parts that may move during transit must be adequately secured.
WARNING Make sure the articulation lock is in the transport position before you transport the machine.
The articulation lock must also be in the transport position if you are carrying out daily checks or doing any
maintenance work in the articulation danger zone. If the articulation lock is not in the transport position you
could be crushed between the two parts of the chassis.
WARNING Always make sure the articulation lock has been removed before attempting to drive the
machine. The machine cannot be steered with the articulation lock installed.
CAUTION You can be injured if you use incorrect or faulty lifting equipment. You must identify the weight of
the item to be lifted then choose lifting equipment that is strong enough and suitable for the job. Make sure
that lifting equipment is in good condition and complies with all local regulations.
Before transporting the machine make sure you will be obeying the rules and laws of all the areas that the
machine will be carried through.
Make sure that the transporting vehicle is suitable for the dimensions of your machine, refer to Specifications,
Static Dimensions.
Table 8. Lashing Capacity
Force Proof Force Breaking Force
Forward 5,896 N 7,370 N 11,792 N
Backward 5,896 N 7,370 N 11,172 N
Laterally 1,801 N 2,252 N 3,603 N
1. Place blocks at the front and rear of the trailer wheels.
To Next Page
