About the Product
Product and Component Identification
12 9831/7750-1 12
The engine serial number is stamped on the cylinder block. Refer to Figure 5.
The engine data label and emission label are located on the engine top cover. Refer to Figure 5.
Figure 5.
A Stamped engine serial number B Engine data label
C Engine emission label
Operator Protective Structure
WARNING You could be killed or seriously injured if you operate a machine with a damaged or missing
ROPS. If the ROPS has been in an accident, do not use the machine until the structure has been renewed.
Modifications and repairs that are not approved by the manufacturer may be dangerous and will invalidate
the ROPS.
WARNING Do not operate the machine with the ROPS in the folded position except while working within a
building or orchard where vertical space is limited. Take extreme care when operating the machine with the
ROPS in the folded position. Make sure that the ROPS is unfolded after completion of the work.
Machine built to the ROPS (Roll-Over Protective Structure) standard and has data plate attached to lower left
side of ROPS frame.
