10 - 1
Section J Track and Running Gear
9803/6410
Section J
10 - 1
Issue 1
Top Roller
Item Part Name
A Roller
B Plug
C Circlip
D Cover
E ‘O’-ring
F Bolt
G Thrust plate
H Shaft
I Floating seal
J Bush
K Bush
L Mounting bracket
JS01540
