9 - 2
Replacement
1 Before fitting the roller, check the oil level and, if
necessary, top up (see Fluids and Lubricants, Section
3). Install the plug using an appropriate pipe thread
sealant.
2 With the track supported as shown under Removal,
step 2, install the roller. Apply Loctite 262 to the threads
and fit the mounting bolts.
3 Remove the wooden blocks and jack.
4 Apply grease through the check valve to adjust the
track tension (see Checking/Adjusting the Track
Tension, Section 3).
Section J Track and Running Gear
9803/6410
Section J
9 - 2
Issue 1
Top Roller
