Routine Maintenance
Tyres and Wheels
158 158
9811/5700-7
732160-V2
Fig 125.
Checking the Wheel Nut Torques
T3-014_3
!MWARNING
If, for whatever reason, a wheel stud is renewed, all the
studs for that wheel must be changed as a set, since
the remaining studs may have been damaged.
2-3-2-8
On new machines, and whenever a wheel has been
removed, check the wheel nut torques every two hours
until they stay correct.
Every day, before starting work, check that the wheel nuts
are tight.
Tighten the wheel nuts (in a diagonal sequence) to the
torque value shown.
Table 6.
Front Rear
Nm (lbf ft) Nm (lbf ft)
680 (500) 680 (500)
