28 - English

Repair Instructions

7.6 Dismantling the ignition module

and ﬂywheel

Remove the cylinder cover. Remove the starter.

Snap off the ignition cable from the guide rail and

remove the guide rail. See gure 1.

Thread the mandrel on the crank pin. Screw in until

1-2 threads are left to the ywheel. Knock on the

mandrel with a suitable metal hammer while at the

same time pulling the ywheel outward until the

ywheel comes off the shaft. Remove mandrel and

ywheel. See gure 3.

Unscrew the air nozzle to replace the ignition mod-

ule. Loosen the screws on the ignition module. See

gure 4.

Dismantle the air lter, air lter holder and carburet-

tor. See the “Dismantling the carburettor” chapter.

Dismantle the tank unit as outlined in the “Disman-

tling the tank unit” chapter.

Dismantle the intake system, see the “Dismantling

the intake system” chapter.

Loosen the earth cable. See gure 11. Pull the

cables through the openings in the crankcase.

Cleaning and inspection

• Clean all parts, especially the tapers on the

ywheel and shafts.

• Check the ywheel for cracks or any other signs

of damage.

Knock out a few of the pins in the tool if it does not

match up with the ywheel.

Use the tool to hold the ywheel in place while the

ywheel nut is loosened using a suitable socket

wrench. See gure 2.

Fig 1

Fig 2

Fig 3

Fig 4
