When replacing the fuel lter, the old fuel lter must
be taken out of the tank unit using special tool
502 50 83-01.
2
Pull out fuel hose B from the tank unit and pull
away the lter A. See gure 58.
3
Fit the new fuel lter A and press the
fuel hose back into place.
7.19 Replacing the fuel hose/return hose
The fuel hose is moulded and can only be removed
from outside of the fuel tank.
Use suitable pliers with a smooth cutting face and
loosen the hose B from the fuel tank. See gure
58. Replace the return hose when required. Tight-
en the fuel hose on the lter side with your ngers.
7.20 Replacing the fuel pump (Purge)
Dismantle
1. Dismantle the cylinder cover and the air lter.
2. Loosen suction hose C and return hose from
the fuel pump. See gure 59.
3. Snap off the fuel pump from the lter holder.
Assembling
1. Snap the fuel pump in place in the lter holder.
See gure 59.
2. Fit the return and suction hose on the fuel
pump.
3. Assemble the air lter and cylinder cover.
NOTE!
Fluted pliers may not be used with the fuel
hose. They can cause material damage
resulting in damage to the fuel hose.
Repair Instructions
7.18 Replacing the fuel filter
Fig 59
Fig 58
