jotron TR-810 User Manual

1 Introduction
1.1 Models covered by this manual
The following models /versions are covered by this manual
Model
P/N
Accessories
Output
Frequency
Mode
TR-810 Transceiver, Vehicle (VE)
86417
See Table 1.1-2
10 Watt
118-137 MHz
AM
TR-810 Transceiver, Desktop (DE)
86419
See Table 1.1-2
10 Watt
118-137 MHz
AM
TR-810 Transceiver, Offshore (OF)
86420
See Table 1.1-2
10 Watt
118-137 MHz
AM
TR-810 Transceiver, Last Resort (LR)
86418
See Table 1.1-2
10 Watt
118-137 MHz
AM
TR-810 Transceiver, Man Portable (MP)
86416
See Table 1.1-2
5 Watt
118-137 MHz
AM
Table 1.1-1, Radio models
Accessory
X = Standard supply O = Optional supply
Part
No
TR-810
VE
TR-810
DE
TR-810
OF
TR-810
LR
TR-810
MP
5m extension cable for split mount
84317
X
X
Hand microphone
84092
X
X
X
X
X
Console bracket
84084
X
X
X
X
Lock screws
84086
X (4 pcs)
X (4 pcs)
X
X (8 pcs)
Washer
90318
X
X (8 pcs)
Bracket front module (for split mount)
84414
X
X
X
Operation and Installation manual
84417
X
X
X
X
X
Antenna with cable (Vehicle kit)
97976
X
Antenna adapter FME - BNC
84605
X
DC cable with fuses for vehicle mount
84329
X
External Speaker
85558
X
Screw M4x10 Unbrako
82276
X
X
X
Screw M4x8 Unbrako
99823
X
Spacer M4x2mm
86652
X
Power AC/DC with connector
84330
X
X
X
220V AC cable w/plugs
92375
X
X
X
X
DC/DC converter with separation
84545
O
Antenna adapter BNC - N
80577
X
X
X
Front cover plate with flange (for split mount)
84082
O
X
Console cover plate (for split mount)
84416
O
X
Base antenna
91794
O
Coax cable RG-213 – 30m
97898
O
N-connector for RG-213
98244
O
Antenna ½``flammable retardant cable
82907
O
N-connector for ½``flammable retardant cable
82908
O
Antenna lightning protector
80322
O
O
O
Technical manual
84096
O
O
O
O
O
Power AC/DC with lighter-connector
86918
X
Antenna
86875
X
Shoulder bag
85636
X
BU-872, Battery Backup
87130
X
X
Discharge unit
86991
O
O
Antenna bracket
85778
X
Fasten bracket
85779
X (2 pcs)
X
DC power cable
86026
X
Interconnection cable
85783
X
Antenna cable w/connector
85781
X
Support knob
97975
X
Insertion for carrying bag
86409
X
Bundle strips 95x2,5mm
96943
X
Table 1.1-2, Accessory list
84417_O&I_TR-810_G  Introduction
Page 1-10
