4 Installation
4.1 Compass safe distance
The Compass safe distance for the TR-810 is minimum 110cm.
4.2 Introduction.
The procedure for installing the transceiver are described in Table 4.2-1 below.
It is recommended that these procedures are completed in the order shown.
Procedure
Reference
1
Initial inspection
4.3
2
Install equipment
4.4
4
Connect remote connectors as required
4.7
5
Connect antenna
4.5
6
Connect DC supply
4.6
Table 4.2-1, Installation procedures
4.3 Initial inspection
Items included for a TR-810 transceiver
1
TR-810 transceiver
2
CD with Operators Manual
3
Accessories ordered according to model and installation. See Table 1.1-2,
Accessory list
Table 4.3-1, Inspection procedures
On receipt of the radio unit, remove all transit packaging and check that there is no damage
to the equipment. If damage is evident, contact Jotron AS immediately and retain the
original transit packaging.
84417_O&I_TR-810_G  Installation
Page 4-1
