5.6 Bite information menus – transceiver
Under the menu selection from the Bite menu, various submenus are available for the
technician. The submenus and details for them are shown in the tables below.
Menu path: Bite
Parameter:
Range
Default
Details
Temp PA
-20 °C to +95 °C
32°C
Alarm Temp Pa
Internal temperature of the RF Module is out of
range (above 85˚C).
Fwd power
0,2W to 10W
10W
Alarm Pwr
Transmitted output power
is below 0.2W.
SWR
0W to 10W
0W
Alarm SWR
Reflected power exceeds threshold.
Possible faults:
Defective antenna, antenna cable, cavity filter out of
tune etc.
Input volt
10VDC to 28VDC
13,8V
RSSI
1.1 V at 1 uV
0,9V
12V
10VDC to 14VDC
12V
Alarm 12V
The +12V is out of range.
5 volt
4,3VDC to 5,6VDC
5V
Alarm 5V
The +5V is out of range.
5 volt REF
4,3VDC to 5,6VDC
5V
Alarm 5V REF
The +5V_REF is out of range.
3 volt
2,7VDC to 3,3VDC
3V
Alarm 3V
The +3V is out of range.
Current
< 5A
4,0A
Alarm Cur
The current consumption in the transceiver is too
high (above 5A).
IF current
20mA to 60mA
40mA
Alarm IF
The current consumption in the 1 IF circuit is out of
range.
LNA current
35mA to 55mA
43,5mA
Alarm LNA
The current consumption in LNA is out of range.
Modulation
0% to 100%
90%
Synth TX
Alarm Synth TX
Transmitter synthesizer is out of lock.
Synth RX
Alarm Synth RX
Receiver synthesizer is out of lock.
Table 5.6-1, Submenus available on the Bite menu
84417_O&I_TR-810_E  Operating Instructions
Page 5-8
