5.2 User menu – transceiver, Restricted access level
Main display window in restricted mode.
When the transceiver is switched on, it will show the name of the last
selected channel and the frequency. This is the start-up menu.
Any fault indications will be shown at the bottom line of the display.
Rotating will set the volume in the front speaker and, if connected
and activated, also the remote speaker.
Press to Save the speaker volume level. Press to go one step back.
Press to navigate to the channel recall screen.
Select any channel (up to 63) that is previously stored in the transceiver, by
rotating . Press to Recall the selected channel.
Press to navigate to the squelch adjustment screen.
This setting adjusts the squelch operating level.
Rotate CW or CCW to adjust the squelch operating level.
Press to Save the selected squelch operating level.
Press to access the Main menu options available for the current user
level. Select sub-menu by rotating .
Press to navigate to the Display contrast adjustment screen.
Rotate CW or CCW to adjust the Display contrast level.
Press to save the selected squelch operating level.
Select sub-menu for System software information by rotating .
Press to navigate to the System software information screen.
Press to return to Main menu.
The Transceiver Ctrl submenu is for non-restricted users and technicians
only.
Press to navigate to the Transceiver Ctrl information screen.
For details refer to chapter 5.3.
Table 5.2-1, User menu selections transceiver - restricted access level
84417_O&I_TR-810_E Operating Instructions
Page 5-3
