JUKI LS-1300 Series User Manual

−28 −
Standard Adjustment
(2) Alternate vertical dial
1
2
8±0.1 mm
Alternate
vertical dial
Detection switch of amount of
alternate vertical movement
Bushing
Convex section
Top cover
Spring
Pin
Hole of section A
Red
Green
White
Black
Amount of alternate vertical
movement of the walking foot and
presser foot
Less than 2.5 mm
2.5 mm to less than 4 mm
4 mm to less than 4.75 mm
4.75 mm to less than 6.5 mm
Stitch length :
6 mm or less
2500 rpm
2200 rpm
1800 rpm
1600 rpm
™ Sewing speed of LS-1342 and LS-1342-7
Standard Adjustment
5) Thread trimmer cam timing
1) Installing position of the detection switch of the amount of alternate vertical movement
Engraved marker dot
on machine arm
Red engraved
marker dot
Handwheel
1
2
3
4
To come in close contact
with each other
Hook driving shaft
Section R comes in close contact
with thread trimmer cam roller.
Conditions : Engraved marker dot on handwheel is aligned with engrared marker dot on machine arm.
