− 40 −
1
2
3) Installing the 5-step switch
Attach 5-step switch (asm.) 1 with setscrews 2.
Part No.
21442553
SS711084SP
No.
1
2
Note Name of part
5-step switch (asm.)
Setscrew
Q’ty
1
2
◎ 5-step switch components
(4) Knee lifter shaft (pedal type)
6
7
8
9
!0
!1
!2
1
2
3
4
5
To come in contact
with each other
To align the edges with
each other
To come in contact with each other
Part No.
21339601
21437108
No.
1
2
Note Name of part
Top feed stopper plate A
Window plate E
Q’ty
1
1
◎ Removing parts list of DL device
Part No.
GDL21000AB0
No.
1
Note Name of part
Kit DL-21 (Without AK knee switch)
Q’ty
1
◎ Installing parts list of DL device
To Next Page
