6. SELECTIVE PARTS AND CONSUMABLE PARTS
™ Common to all models
Name of selective part Part No. Marking Remarks
Hook shaft washer B1820246000 0 t=2.1 mm
Hook shaft washer B182024600A 1 t=2.05 mm
Hook shaft washer B182024600B 2 t=2.0 mm (standard)
Hook shaft washer B182024600C 3 t=1.95 mm
Hook shaft washer B182024600D 4 t=1.9 mm
Name of consumable part Part No. Remarks
Moving knife 21440607
Fixed knife 21440102
Clamp plate 21440201
™ For LS-1342-7
Name of consumable part Part No. Remarks Model
Needle MC372001600
SCHMETZ DP X 17 Nm 160
LS-1341/42/42-7
Needle MC372001400
SCHMETZ DP X 17 Nm 140
LS-1340
Hook (asm.) B18013400A0 Latch hook LS-1340
Hook (asm.) 21431358 Cap hook LS-1341
Hook (asm.) 21431457 Latch hook LS-1342
Hook (asm.) 21441753 Latch hook LS-1342-7
Bobbin B9117051000 LS-1340
Bobbin B9114201000 LS-1341/42
Bobbin 10759603 Aluminum bobbin LS-1342-7
Name of selective part Part No. Marking Remarks
Moving knife base thrust plate B185351200AA A t=2.7 mm
Moving knife base thrust plate B185351200BA B t=2.6 mm
Moving knife base thrust plate B185351200CA C t=2.5 mm (standard)
Moving knife base thrust plate B185351200D D t=2.4 mm
Moving knife base thrust plate B185351200E E t=2.3 mm
