− 13 −
(3) Setting for functions of SC-510
Functions can be selected and specified by means of the four setting switches and light emitting diode
located inside the front cover of the SC-510.
There are two modes of the user's level (indicated as U) and the service level (indicated as S) in the function
setting modes.
How to change over to the function setting mode
(Caution) 1. Do not perform switch operations other than those described in the following explanations.
2. Be sure to re-turn the power switch ON after one second or more has passed. If the power
is turned ON immediately after turning it OFF, the sewing machine may not work normally.
In this case, turn ON the power again.
[ How to change over to the function setting modo ]
1. Changing over to the user's mode
(1) Turn OFF the power to the unit.
(2) Pressing switch 4, turn ON the power to the unit.
2. Changing over to the service mode
(1) Turn OFF the power to the unit.
(2) Pressing switch 4, turn ON the power to the unit.
(3) Keep pressing switch 4 for three seconds
even when the indication is shown on the
display.
(4) The service mode starts when the buzzer has
sounded two times.
3. Indication 5, 6 will be shown on the display. (If
the indication fails to change, re-perform the
procedures (1) and (2).
1
2
3
4
5
6
4
4
1 Switch for entering specified value changed and
updating setting No. in DOWN direction (SET–)
2 Switch for entering specified value changed and
updating setting No. in UP direction (SET+)
Specified value
Specified No.
3 Down switch (DOWN)
4 Up switch (UP)
To Next Page
