JUKI SC-510 Engineer's Manual

−15 −
* Do not change the set values with asterisk (*) mark as they are functions for maintenance. If the standard set value set at the time
of delivery is changed, it is in danger of causing the machine to be broken or the performance to be deteriorated.
(Descriptions of setting in this list are the standard values at the time of delivery.)
However, contents of function setting are subject to change for improvement of function and performance without notice.
(4) Function setting list (Start level ; U : User's mode, S : Service mode)
Indication of
function setting
Item
Soft start
function
Material end
sensor function
Thread trimming
function by
material end
sensor
Number of
stitches for
material end
sensor
Flicker
reducing
function
Bobbin thread
counting
function
Unit of bobbin
thread
counting down
Number of
rotation of
reverse feed
stitching
Thread
trimming
prohibiting
function
Setting of
needle bar
stop position
when the
sewing
machine stops.
Click sound of
key switch
mounted on
PSC
Optional input/
output setting
Function of
prohibiting start
of the sewing
machine by
bobbin thread
counter
Sewing counter
Function of
reverse feed
stitching switch
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
0 to 9
(Stitches)
0/1
0/1
0 to 19
(Stitches)
0 to 3
0/1
0 to 2
150 to 3,000
(rpm)
0/1
0/1
0/1
0 to 2
0/1
0 to 3
Description
The number of stitches to be sewn at a low speed when the soft-start
function is used at the start of sewing.
0 : Soft-start function is not operative.
Material end sensor function (used in case of without panel).
0 : Material end detection function is not operative.
1 : After detecting material end, the specified number of stitches
(No. 4) will be sewn, and the sewing machine will stop.
Thread trimming function by material end sensor (used in case of
without panel).
0 : Automatic thread trimming function after detection of material
end is not operative.
1 : After detecting material end, the specified number of stitches
(No. 4) will be sewn, and the sewing machine will stop and
perform automatic thread trimming.
Number of stitches for material end sensor (used in case of without
panel).
Number of stitches from detection of material end to stop of the sewing
machine.
Flicker reducing function (If the hand lamp flickers).
0 : Flicker reducing function is not operative.
1 : Less effective / 3 : Highly effective
Bobbin thread counting function
0 : Bobbin thread counting function is not operative.
1 : Bobbin thread counting function is operative.
Unit of bobbin thread counting down
0 : Count/10 stitches
1 : Count/15 stitches
2 : Count/20 stitches
Sewing speed of reverse feed stitching
Thread trimming prohibiting function (used in case of without panel).
0 : Thread trimming prohibiting function is not operative.
1 : Thread trimming is prohibited.
(Output of solenoid is prohibited. : Thread trimmer and wiper)
Position of needle bar is specified when the sewing machine stops.
0 : Predetermined lowest position
1 : Predetermined highest position
Click sound of key switch mounted on PSC is specified.
0 : Click is not operative.
1 : Click is operative.
Changeover of optional switch.
Function of prohibiting start of the sewing machine by bobbin thread
counting
0 : When counting is out (-1 or less) Function of prohibiting start
of the sewing machine is not operative.
1 : When counting is out (-1 or less) Function of prohibiting start of
the sewing machine after thread trimming is operative.
2 : When counting is out (-1 or less), the sewing machine stops
once. Function of prohibiting start of the sewing machine after
thread trimming is operative.
Counting function of sewing (number of completion of process)
0 : Sewing counter function is not operative.
1 : Sewing counter function is operative.
Function of reverse feed stitching switch is set.
0 : Normal BTsw
1 : Level input wrapper control and presser synchronizing control
2 : Level input wrapper control
3 : Alternate input wrapper control
*
Ref.
page
20
20
20
20
20
20
20
20
20
21
24
24
24
1
0
2
0
9
0
10
0
11
1
12
0
18
Function of
alternate
vertical amount
input
Function of alternate vertical dial of LU series is selected.
0 : Invalid
1 : Analog input (analog optional input)
2 : Digital input (digital input 2 input)
0/1/2
3
0
4
5
5
0
6
1
7
0
18
0
15
0
14
1
13
0
8
1900
Setting
range
Start
level
U
U
U
U
U
U
U
U
U
U
U
U
U
U
S
