Creating Classifier Groups and Policy Rules ! 41

Chapter 2: Creating Policies

! Use the suspend version to suspend the mark DE rule within the classifier

group.

! Use the no version to remove the mark DE rule from the classifier group.

mark-exp

! Use to assign a value in the range 0–7 to the MPLS EXP field for packets

conforming to the current CLACL.

! Example

host1(config-policy-list-classifier-group)#mark-exp 5

! Use the suspend version to suspend the mark EXP rule within the classifier

group.

! Use the no version to remove the mark EXP rule from the classifier group.

mark-user-priority

! Use to assign a value in the range 0–7 to the 802.1p VLAN priority field for

packets conforming to the current CLACL.

! Example

host1(config-policy-list-classifier-group)#mark-user-priority 5

! Use the suspend version to suspend the mark-user-priority rule within the

classifier group.

! Use the no version to remove the mark-user-priority rule from the classifier

group.

next-hop

! Use to define the IP address of the next hop to which the packets are forwarded

for packets conforming to the current CLACL.

! For IP interfaces, this command is supported only on input policies.

! Example

host1(config-policy-list-classifier-group)#next-hop 10.10.10.1

! Use the suspend version to suspend the next-hop rule within the classifier

group.

! Use the no version to remove the next-hop rule from the classifier group.

NOTE: The forward next-hop command replaces the next-hop command. The

next-hop command may be removed in a future release. See the forward

next-hop command for details.

The SRP module Fast Ethernet port cannot be the destination of the next-hop

command.
