Network Processing Card SRX3K-NPC
Network Processing Cards (NPCs) are CFMs that receive inbound traffic from the IOCs
and direct it to the appropriate SPC for services processing. Once services processing is
complete, the NPC receives outbound traffic from the SPC(s) and directs it back to the
appropriate IOC. Additionally, the NPC performs the following functions:
•
Buffers incoming traffic and queues outgoing traffic.
•
Performs advanced traffic management, including DoS/DDoS protective measures.
For example, it can drop traffic to or from a particular IP address, protecting from ICMP,
UDP, and TCP SYN flooding, and buffering bursty traffic to protect the SPC.
Figure 11: Network Processing Card SRX3K-NPC
•
NPC for SRX3400, SRX3600, and SRX1400
•
Power requirement: 64 W maximum
•
Weight: 2.2 lb (1.0 kg)
Description
•
Junos OS Release 9.3 and laterSoftware release
NoneCables and connectors
ONLINE Button–The ONLINE button on the NPC front panel does not perform any function.Controls
•
SRX1400: Front slot labeled 3 when installed in conjunction with an SPC installed in slot 1.
•
SRX3400: Rear slots labeled 5 through 7.
•
SRX3600: Rear slots labeled 10 through 12.
Supported Slots
NPCs are cold-swap-only modules. You must power-off the services gateway before removing,
replacing, or adding NPCs.
Swapping
Copyright © 2016, Juniper Networks, Inc.16
SRX1400, SRX3400, and SRX3600 Services Gateway Module Guide
