8. If you are installing additional CFMs at this time, repeat steps 3 through 7.
9. Insert the appropriate cables into the cable connector ports on each CFM as applicable.
Secure the cables so that they are not supporting their own weight. Place excess cable
out of the way in a neatly coiled loop. Placing fasteners on a loop helps to maintain
its shape.
10. If you inserted hot-swappable CFMs without powering off the services gateway, bring
each new CFM online by pressing its ONLINE button for five or more seconds to power
it on and bring it online.
WARNING: Never lift the services gateway using the handles on the front
panels of the CFM cards. The handles might come off, causing the chassis
to drop and inflicting possible grave injury.
Related
Documentation
SRX1400, SRX3400, and SRX3600 Services Gateway Module Overview on page 2•
• Modules Supported on SRX1400, SRX3400, and SRX3600 Services Gateways on
page 3
• Eligible Slots for SRX1400, SRX3400, and SRX3600 Services Gateway Modules on
page 4
Installing Routing Engines and SRX Clustering Modules In SRX1400, SRX3400, and
SRX3600 Services Gateways
To install a Routing Engine or SRX Clustering Module (SCM):
1. Place an electrostatic bag or antistatic mat on a flat, stable surface.
2. Attach an ESD grounding strap to your bare wrist and connect the strap to one of the
ESD points on the chassis. For more information about ESD, see the hardware
documentation for your services gateway.
3. If you have not already done so, power off the services gateway by pressing the Power
button on the front panel of the Switch Fabric Board (SFB) for three to five seconds.
The PWR LED blinks to show you that the services gateway is shutting down. Wait for
the services gateway to shut down before you proceed to the next step.
4. Identify the slot in the services gateway where you are installing the Routing Engine
or SRX Clustering Module:
•
On SRX1400 Services Gateways, Routing Engines always go in slot RE
•
On SRX3400 and SRX3600 Services Gateways, Routing Engines always go in slot
RE0
•
SCMs always go in slot RE1
5. Carefully align the sides of the Routing Engine or SCM with the guides inside the
chassis.
23Copyright © 2016, Juniper Networks, Inc.
Installing Routing Engines and SRX Clustering Modules In SRX1400, SRX3400, and SRX3600 Services Gateways
