9
SDI Rec Trigger
For
setting whether to superimpose trigger signals
in tandem with the [HD/SD SDI OUT] terminal as
well as the [REC] button on the camera body.
When a compatible device is connected,
recording/stop control signals are output in tandem
with the operation of the [REC] button.
Both REC/STBY and Display are displayed.
[Setting Values: On, ROff]
SD Aspect
For setting the style of displaying down-converted
images on a 4:3 aspect ratio screen.
0
Side Cut:
Displays image with the left and right sides cut
off.
0
Letter:
Displays as a wide image with the top and
bottom blackened.
0
Squeeze:
Displays image that is squeezed horizontally.
[Setting Values: Side Cut, Letter, RSqueeze]
Memo :
0
When [Record Format
] B [System] is set to
“SD”, and when [SD Aspect] is set to “4:3”, this
item appears as “---” and cannot be selected.
(A P
112 [ System ] )
SD Set Up
For selecting whether to add a setup signal to the
video signal output from the
[AV] output terminal.
Setup signals are added when “7.5%” is selected.
[Setting Values: 7.5%, 0.0%]
(Default values: 7.5% (U model), fixed at “0.0%” (E
model))
Memo :
0
Depending on the menu settings of the camera
recorder and the condition of the cable
connected to it, the setup signal setting may be
fixed
at “0.0%”. “0.0%” is displayed in gray in this
case.
Audio Set Item
Input1 Mic Ref.
For setting the reference input level when the
[INPUT1] selection switch is set to
“MIC” or “MIC
+48V”.
[Setting Values: -62dB, -56dB, R-50dB, -44dB,
-38dB]
Input2 Mic Ref.
For setting the reference input level when the
[INPUT2] selection switch is set to
“MIC” or “MIC
+48V”.
[Setting Values: -62dB, -56dB, R-50dB, -44dB,
-38dB]
Int. Mic Gain
For
setting the sensitivity of the built-in microphone.
[Setting Values: +12dB, +6dB, R0dB]
AUX Gain
For setting the sensitivity of the [AUX] terminal
input.
[Setting Values: +12dB, +6dB, R0dB]
Ref. Level
For
setting the audio reference level to be recorded
to the SD card. (Applies to both [CH1/CH2].)
[Setting Values: -12dB, -18dB, R-20dB]
Limiter
For setting the limiter operation.
0
Ref. Level:
Sets “Ref. Level
” to the maximum recording
level.
0
-8dBFS, -5dBFS:
Sets “-8dBFS” or “-5dBFS” to the maximum
recording level.
0
Off:
Depending on the settings of the [CH1/CH2
AUTO/MANUAL]
selection switches, the
operation may be different as described below.
0
The limiter does not function when
“MANUAL” is set.
0
The limiter functions at -5 dBFS when
“AUTO”
is set.
[Setting Values: Ref. Level, -8dBFS, R-5dBFS,
Off]
AGC Response
9
Attack Time
Sets the time to activate the limiter.
[Setting Values: Fast, RMiddle, Slow]
9
Decay Time
Sets the time to deactivate the limiter operation.
[Setting Values: Fast, RMiddle, Slow]
108
Menu Display and Detailed Settings
