48
OTHER EXTERNAL COMPONENTSOTHER EXTERNAL COMPONENTS
Using the rear view camera
• To connect a rear view camera, see page82 .
• To use a rear view camera, a REVERSE lead
connection is required. (Pages 79 – 80 )
❏ Settings for the rear view camera
1 Display the <Settings> screen.
On the Home screen:
KW-V330BT KW-V430BT
KW-V630BT
KW-V230BT
2 Display the <Input> setting screen.
3 Display the <Rear Camera> screen.
4
[ON] Displays the picture from the rear view
camera when you shift the gear to the
reverse (R) position.
[OFF] Select this when no camera is
connected
❏ Displaying the rear view camera screen
To display the picture from the rear view camera
The rear view screen is displayed when you shift the
gear to the reverse (R) position.
• To remove the caution message, touch the screen.
To display the picture from the rear view camera
manually
KW-V230BT
KW-V330BT
KW-V430BT
KW-V630BT
• Only for KW-V230BT /KW-V430BT /KW-V630BT : You
can also display the picture from the rear view
camera by selecting [Camera] (for KW-V230BT )/
[ ] (for KW-V430BT /KW-V630BT ) on the pop-up
short-cut menu (Page12).
To exit the camera screen
Press HOME on the monitor panel.
• You can also exit the camera screen by touching
the area shown below.
2017KW-VEntryK.indb482017KW-VEntryK.indb48 2016/12/0915:112016/12/0915:11
To Next Page
