47
Maintenance
Dimensions
414.8 mm x 275.9 mm x 116 mm (W x D x H)
Unit: mm
275.9
414.8
116
289.7
291.2067.12
35.74
31
164.1
172.26
3.5
Ceiling mount screws: M5
(Max. L = 25 mm; Min. L = 20 mm)
58.22
58.77
