Country-
spec.
Settings
Men
u
leve
l
Display/
Setting
Action in this menu/meaning
Activation threshold
with overfrequency
50.2 – 70 (Hz)
Activation threshold
with underfrequency
40 – 45 (Hz)
Activation threshold (f1) overfrequency:
Determines the frequency threshold for activating the function in case
of overfrequency incidents. The active power adjustment is activated if
the frequency rises above the configured value and mode 1 or 2 is acti-
vated.
In mode 2, the function is deactivated if the frequency falls below the
configured value.
Activation threshold (f1) underfrequency:
Determines the frequency threshold for activating the function in case
of underfrequency incidents. The active power adjustment is activated if
the frequency falls below the configured value and mode 1 or 2 is acti-
vated.
In mode 2, the function is deactivated if the frequency rises above the
configured value.
P(f) intentional delay
0 – 5000 [ms]
Activation of the function is delayed by the configured time based on
the activation threshold.
Note 1: This function is regarded as critical for the stability of the trans-
mission grid and is therefore prohibited by several national grid connec-
tion regulations.
Note 2: This function is stipulated as a requirement by some domestic
grid connection directives in order to prevent any negative impact on is-
land detection. However, P(f) has no negative impact on KACO's en-
hanced island detection.
Frequency of the maxi-
mum deactivation
threshold
45 - 50.2 (Hz)
Frequency of the mini-
mum deactivation
threshold
45 – 50.2 (Hz)
Deactivation range lower limit:
Only evaluated in mode 1.
The function is deactivated if the frequency returns to the deactivation
range and remains in this range for the duration of the deactivation
time.
Deactivation range upper limit:
Only evaluated in mode 1.
The function is deactivated if the frequency returns to the deactivation
range and remains in this range for the duration of the deactivation
time.
P(f) deactivation time
0 – 3600 [s]
Only evaluated in mode 1.
The function is disabled if the frequency returns to the range between
the minimum and maximum deactivation threshold and remains within
this range for the duration of the deactivation time.
P(f) deactivation gradi-
ent
0 - 65534 [% / min]
If, upon deactivation, the power level available is higher than the actual
power level, then the power increase is limited to the maximum power
level. The limitation is implemented using an absolute power limit which
increases up to the maximum power level with a continuous gradient.
The actual power of the inverter may vary freely below this limit due to
a possible fluctuation in the available power or the target value, but at
no time increases above the absolute power limit.
Dynamic gradient
mode
On | Off
F Activate dynamic gradient.
10 | Specifications Manual
KACO blueplanet 87.0 TL3 KACO blueplanet 92.0 TL3 KACO blueplanet 105 TL3 KACO blueplanet 110 TL3
KACO blueplanet 125 TL3 KACO blueplanet 137 TL3 KACO blueplanet 150 TL3 KACO blueplanet 155 TL3
KACO blueplanet 165 TL3
