Initial short-circuit alternating
current (Ik" first single period
effective value)
16.5 A 18.9 A 16.5 A 18.9 A
Short circuit current continu-
ous [ms] (max output fault cur-
rent)
1.3 A
Inrush current 1.033 A [RMS (20ms)]
Rated frequency 50/60 Hz
Frequency range 45 - 65 Hz
Reactive power 0 - 95% Snom
cos phi 0.3 - 1 ind/cap
Number of feed-in phases 3
Distortion factor (THD) 0.36 % 0.32 % 0.31 % 0.29 % 3.85 % 0.27 %
Max. voltage range (up to 100
s)
287.5 V / 500 V
AC overvoltage protection no
4.2 General Data
3.0 TL3 4.0 TL3 5.0 TL3 6.5 TL3 7.5 TL3 8.6 TL3 9.0 TL3 10.0 TL3
General electrical data
Max. efficiency 98.1 % 98.2 % 98.3 % 98.5 %
European efficiency 96.6 % 97.1 % 97.4 % 97.6 % 97.7 % 97.9 % 98.3 %
Self consumption: Standby 3 W
Feed-in from 20 W
Transformer unit no
Protection class / over voltage
category
I / III (AC) II (DC)
Grid monitoring Country-specific
Distribution system TN-C-System, TN-C-S-System, TN-S-System, TT-System
3.0 TL3 4.0 TL3 5.0 TL3 6.5 TL3 7.5 TL3 8.6 TL3 9.0 TL3 10.0 TL3
General Data
Display Graphical display + LEDs
Controls 4-way button + 2 buttons
Menu languages DE; EN; FR; IT; ES; PL; NL; PT; CZ; HU; SL; TR; RO
Interfaces Standard: 2 x Ethernet, USB, RS485, optional: S0, 4-DI, 4-DO
Communication TCP/IP, Modbus TCP, Sunspec
Potential-free relay Potential-free NO contact, max. 30V/1A DC
DC isolator switch yes
AC isolator switch no
Cooling Fan
Number of fans 1
Noise emission <53 db(A)
Housing material Aluminium / plastic
HxWxD 522 mm x 363 mm x 246 mm
Weight 30 kg
Manual Technical data | 4
KACO blueplanet 3.0 TL3 KACO blueplanet 4.0 TL3 KACO blueplanet 5.0 TL3 KACO blueplanet 6.5 TL3 KACO
blueplanet 7.5 TL3 KACO blueplanet 8.6 TL3 KACO blueplanet 9.0 TL3 KACO blueplanet 10.0 TL3
Page 13
