NOTE
Depending on the tolerances of the measuring elements, the measured and displayed values are not always
the actual values. However, the measuring elements ensure maximum solar yield. Due to these tolerances, the
daily yields shown on the display/Monitor may deviate from the values on the grid operator’s feed-in meter by
up to 15%.
NOTE
Calculating efficiency by measuring the current and voltage values can lead to misleading results due to the tol-
erances of the measurement devices. The purpose of these measured values is to monitor the basic operation
of the system.
9.4 Menu structure
Display on the LCD
1
2
3
4
Fig.41: Main menu
1 Selected menu option 3 Menu options in the active menu level
2 Name of the active menu level 4 Menu options of the next lower menu level
NOTE
The menu options displayed on screen are dependent on the country and network settings, and may vary ac-
cording to the type of device. Functions restricted to one or more countries are labelled with country codes in
accordance with ISO3166-1.
Symbols used
4
1 2
3
4
Menu level (0,1,2,3) Password-protected menu (password can be re-
quested from KACO customer service)
Display Submenu
Option menu Option box
Setting range
9.4.1 Menu
Country-
spec. Set-
tings
Men
u
level
Display/
Setting
Action in this menu/meaning
4
1 2
3
4
Desktop F Press Right arrow button.
4
1
2
3
4
Measurements F Open Menu: Press the right arrow button or the OK button.
4
1 2
3
4
Generator Displays the DC-side voltage, amperage and power.
4
1 2
3
4
Grid Displays the AC-side voltage, amperage and power.
Manual Configuration and operation | 9
KACO blueplanet 3.0 TL3 KACO blueplanet 4.0 TL3 KACO blueplanet 5.0 TL3 KACO blueplanet 6.5 TL3 KACO
blueplanet 7.5 TL3 KACO blueplanet 8.6 TL3 KACO blueplanet 9.0 TL3 KACO blueplanet 10.0 TL3
Page 35
EN
