Fault LED (red) Status Explanation LED
OS (operating status) – The fault relay releases again. Off
– The device feeds back into the grid again after a country-
specific time period.
11.7 Troubleshooting
The following table lists the possible status and fault messages, the ProLog© status messages that the device
can display by means of the LC display / web interface and the LEDs.
No. Grid
LED
LED Display Status description Action Pers
.
1 Waiting for feed-in The start voltage (pre-)set in the device is
higher than the actual voltage. The device
waits for the solar voltage to exceed an ad-
justable value and for a stable grid.
Check whether the
start voltage was
set too high in the
menu.
B
2 Insufficient generator
voltage / insufficient battery
voltage
Insufficient generator voltage and power,
status before the transition to night shutdown.
Insufficient DC
voltage or voltage
fails under load (in-
sufficient DC power)
a) Compare the
voltage measured
with the no-load
voltage expected. b)
Check if the DC isol-
ator switch is
switched off c)
Check whether a D
B
3 Constant volt. control No MPP control occurs. When feed-in begins,
a constant generator voltage is fed in (85% of
the measured open circuit voltage) for a short
period
a) Does this status
appear in the morn-
ing and evening
when sunlight con-
ditions are poor? b)
Does this status ap-
pear when sunlight
conditions are
good? Please check
the constant voltage
control settings in
the menu. Internal
note: The device
password is re-
quired to alter these
settings
-
4 Yield counter for daily and
annual yields are displayed
In cases of sufficient sunlight, the unit feeds
into the grid with MPP control so as to maxim-
ise yields.
- B
11 | Maintenance and troubleshooting Manual
KACO blueplanet 3.0 TL3 KACO blueplanet 4.0 TL3 KACO blueplanet 5.0 TL3 KACO blueplanet 6.5 TL3 KACO
blueplanet 7.5 TL3 KACO blueplanet 8.6 TL3 KACO blueplanet 9.0 TL3 KACO blueplanet 10.0 TL3
Page 76
