12 English 5.906-246.0 Rev. 01 (09/14)
1 Overflow valve
2 Detergent injector
3 Control pressure injector
4 Pressure holding valve
5 Pressure valves
6 Suction valves
7 Pump head
A Pump head old
B Pump head new
1 Pressure holding valve
6.2 Pump head
6.2.1 Versions
