Kärcher HD 9/19 M / MX User Manual

English 5.906-246.0 Rev. 01 (09/14) 13
Note
Pay attention to installation position of the seals.
1 Bushing
2 O ring
3 Disc
4 High pressure seal
5 Low pressure seal
6 Disc
1 High pressure seal
2 Disc
3 O ring
4 Bushing
5 Disc
6 Washer ring
7 Low pressure seal
8 Spreader ring
6.2.2 High pressure seal / low pressure seal
