Kärcher HD 9/19 M / MX User Manual

32 English 5.906-246.0 Rev. 01 (09/14)
13 Torques
Name Nm
Cylinder head screws 40 - 45
Piston casing 5 - 7
Trigger gun, pressure regulator 40
Screw connection pressure valves 40 - 45
Screw connection pressure switch 15 - 17
Screw connection suction valves 35 - 40
Overflow valve seat 8 - 10
Swash plate 9 - 12
Motor casing 9 - 12
Screw connection overflow valve 30 - 35
Detergent injector 1,5 - 2,5
Screw connection suction cover 12 - 15
Screw fan wheel attachment 9 - 12
