Kärcher HD 9/19 M / MX User Manual

English 5.906-246.0 Rev. 01 (09/14) 25
10 Technical Documentation
Appliance type Piston diame-
ter in mm
Appliance no. Circuit diagram Operating instructions Spare parts list
HD 6/16-4 M 16 1.524.120.0 0.089-003.0 5.964-870.0 5.971-970.0
HD 6/16-4 MX 16 1.524.125.0 0.089-003.0 5.964-870.0 5.972-055.0
HD 7/18-4 M 18 1.524.220.0 0.087-804.0 5.964-870.0 5.972-050.0
HD 7/18-4 MX 18 1.524.225.0 0.087-804.0 5.964-870.0 5.972-121.0
HD 9/19-4 M 16 1.524.320.0 0.087-804.0 5.964-870.0 5.972-122.0
HD 9/19-4 MX 16 1.524.327.0 0.087-804.0 5.964-870.0 5.971-999.0
HD 9/20-4 M 20 1.524.400.0 0.088-885.0 5.964-870.0 5.971-969.0
HD 9/20-4 MX 20 1.524.407.0 0.088-885.0 5.964-870.0 5.972-061.0
10.1 Technical specifications
Type HD 6/16-4 M
1.524-120.0
HD 7/18-4 M
1.524-220.0
HD 9/19-4 M
1.524-320.0
HD 9/20-4 M
1.524-400.0
HD 6/16-4 MX
1.524-125.0
HD 7/18-4 MX
1.524-225.0
HD 9/19-4 MX
1.524-327.0
HD 9/20-4 MX
1.524-407.0
Main Supply
Voltage V 230 400
Current type Hz 1~ 50 3~ 50
Motor rpm 1/min 1400 2800 1400
Connected load kW 3,4 4,7 6,8 6,9
Protection (slow, char. C) A 16
Type of protection IPX5
Maximum allowed net impedance Ohm 0,294+j0,184 - 0,222+j0,139
Extension cord 30 m mm
2
2,5
Water connection
Max. feed temperature °C 60
Min. feed volume l/h (l/min) 600 (10) 700 (11,7) 900 (15) 900 (15)
Suck height from open container (20 °C) m 0,5
Max. feed pressure MPa 1
Performance data
Working pressure MPa 3...16 3...18 4...18,5 4...20
Nozzle size 038 042 053 050
Max. operating over-pressure MPa 19 21 22,5 22
Flow rate l/h (l/min) 300...600
(5...10)
300...700
(5...11,67)
450...890
(5...14,8)
460...900
(7,7...15)
Detergent suck in l/h (l/min) 0...40 (0...0,7)
Max. recoil force of trigger gun N 30 37 49 49
Values determined as per EN 60335-2-
79
Hand-arm vibration value
Hand spray gun m/s
2
< 2,5
Spray lance m/s
2
< 2,5 3,0 1,5
Uncertainty K m/s
2
1
