Note
The pressure switch is not adjustable.
Note
The pressure switch is not adjustable.
5.3 Bottom view
5.3.1 Pump head HD 6/16, HD 9/20
1 High pressure connection
2 Overflow valve
3 Pump head
4 Control piston, pressure
switch
5 Pressure switch Q2/B1
6 Water connection
5.3.2 Pump head HD 7/18, HD 9/19
1 High pressure connection
2 Overflow valve
3 Pump head
4 Control piston, pressure
switch
5 Pressure switch Q2
6 Water connection
