- 30
* with sweeping unit
Technical specifications
MC 50 Classic MC 50 Advanced MIC 34C
Drive speed, forward km/h 20
Drive speed, reverse km/h 8
Working speed km/h 10
Climbing capability (max.) % 15 25
Driven axles 2
Theoretical surface cleaning performance m
2
/h 14000 14000 14000*
Working width mm --- 1400 1400*
Usage duration when tank is full h approx. 12
Engine
Manufacturer -- Yanmar Kubota
Type -- 3TNV 70 3TNV76 D 1105-T
Cylinder capacity cm
3
854 1116 1123
Engine output at 3000 rpm kW/HP 14,6/20 19,2/26 24/34
Torque at 2000 1/min Nm 53 66,6 89
Electrical system
Battery V, Ah 12, 40
Fuel
Fuel type Diesel
Fuel tank capacity l 37
Engine oil type SAE 10W-30
Engine oil volume l 3,4 5,1
Hydraulic oil type SAE 10W-30
Hydraulic oil volume l 20
Oil type of wheel motors GL4/5 75-W90
Oil quantity, wheel motors l 4 x 0.08...0.09
Waste container
Max. unloading height mm --- 1400 1400*
Waste container volume (gross) l --- 500 500*
Maximum load kg --- 565 565*
Side brushes
Side brush diameter mm --- 700 700*
Speed (continuous) 1/min --- 0...150 0...150*
Tyres
Tyres -- 195/55 R10; 6.00i x 10 H2 20x10.00-10 6PR
Tyre pressure MPa (bar) 0,62 (6,2) 0,28 (2,8)
Greases
For points to be lubricated manually -- Multi-purpose grease
Working conditions
Temperature °C -5 ... +40
Air humidity, non-condensing % 0 - 90
Dimensions and weights
Length x width x height mm 2797 x 1212 x 1970 2797 x 1212 x 1970 2626 x 1084 x 1978
Transport weight kg 1150
Permissible overall weight kg 1650 1750
Permissible front axle load kg 900
Permissible rear axle load kg 1200
Drawbar load of lorry hitch (Option) kg 120
Drawing load of lorry hitch (Option), with/without brakes kg 1000/500 1250/750
Turning radius mm 750
Water reservoir l 160
Resulting values as per EN 60335-2-72
Vibration total value on arms m/s
2
<2,5 <2,5
Uncertainty K m/s
2
0,2 0,2
Vibration total value on seat area m/s
2
<0,5 <0,5
Uncertainty K m/s
2
0,1 0,2
Resulting values as per Outdoor2000/14/EG, with reference to EN 60335-2-72
Sound pressure level L
pA
dB(A) 77 76
Uncertainty K
pA
dB(A) 3 3
Sound power level L
WA
+ Uncertainty K
WA
dB(A) 103 104
32 EN
