Kärcher MIC 34C User Manual

- 5
1 Door handle *
2 Steering column *
3 Work light
4 Steering wheel
5 Ceiling panel *
6 Tank lid
7 License plate holder
8 Hydraulic oil sight glass
9 Balance weight with attachment hitch
10 Container windshield washer system
11 Drive light/direction indicator
12 Tank indicator
F = full
E = empty
13 Pedals *
14 Ventilation/air conditioning (option) *
15 Accessory blower *
16 Panel *
17 Driver's seat *
18 Emergency hammer
* see detailed view below
1 Switch ventilator blower
2 Temperature regulator of heater
3 Cooling capacity regulator (option)
The accessory blower prevents the wind-
shield from fogging up.
1 Switch accessory blower
1 Indicator lamp for directional indicator
2 Switch for warning system
3 Clamp screw for steering wheel height
adjustment
4 Indicator lamp for parking brakes
5 Clamp screw for steering wheel inclina-
tion adjustment
6 Left indicator
7 Horn
8 Right indicator
9 Light off
10 Parking light
11 Dipped beam
12 Hourmeter for sweeping operation,
working hydraulics
13 Full beam
14 Flashing
Overview MIC 34C
Ventilation/air conditioning (option)
Accessory blower
Steering column
12
13
14
7EN
